Solenoid Valve U401-A
bookmark this page Bookmark This Page
print this page Print This Page
live messenger Live Messenger
skype me Skype Me
e-mail us info@yc-fc.com
Send Inquiry
catalogue download Catalogue Download

The flow control valve has been tested and granted Ex approval.The Ex-approval is EX m II T4.Ex certificate number is CE021037.
fuel dispenser
fuel dispenser
fuel dispenser
Materials:
Body: Die cast aluminum alloy
Technical Specifications:
fuel dispenser Power:AC220 V,2×4W
fuel dispenser Current Consumption: big flow valve 18mA, small flow valve 18mA
fuel dispenser Allow flow rate:65L/min,big flow rate:50L/min,small flow rate:5L/min.
fuel dispenser Working pressure:0.035-0.035MPa
fuel dispenser Environmental Condition:-40℃~+70℃
Features:
fuel dispenser A high advantage in reliability and adaptability.
fuel dispenser Housing: Die cast aluminum alloy.
fuel dispenser Dual flow control valves have three grades of big flow, small flow and close.
fuel dispenser The fuel resistant cable can be customized regarding length.
fuel dispenser 100% Factory Tested.
Wiring:
Color Link
Brown communal terminal
Black big flow rate
white small flow rate
Yellow/green ground
Package:
Product ID Weight Dimension
U401-A 2.1kg/case of 130 ×116× 80mm/case of 1
Ordering Specifications:
Product ID Allow flow rate
U401-A 65L/min
